Ubiquiti UniFi AI Theta 360 Lens
This ultra-wide 360° view lens seamlessly integrates with the AI Theta Hub, providing a high-resolution 4K (9MP) view for panoramic coverage of large, busy spaces such as entrances, lobbies, and retail floors. It can be easily mounted on flat ceilings or walls using the included Standard Flush Mount.
Tech Specs
| Device Specifications | |
|---|---|
| Overview | |
| Dimensions | Ø22.8 x 43.5 mm (Ø0.9 x 1.7”) |
| Field of View | H: 180° V: 180° D: 180° |
| Resolution | 4K |
| Mounting | Wall, ceiling mount (Included) Angle mount (Optional) |
| Operating Environment | Indoor only |
| Performance | |
| Image Settings | Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay |
| Max. Frame Rate | 20 FPS |
| Video Resolution | 4MP 2560 x 2560 (1:1) |
| Sensor | 12MP CMOS |
| Lens | Fixed focal length |
| Hardware | |
| Enclosure Material | Aluminum alloy, polycarbonate |
| Mounting Material | Polycarbonate |
| Weight | 15 g (0.5 oz) |
| Power Method | Theta proprietary |
| Power Supply | 5V DC, 0.5A |
| Max. Power Consumption | 2.5W |
| Operating Temperature | -20 to 40° C (-4 to 104° F) |
| Operating Humidity | 10 to 90% noncondensing |
| Certifications | FCC, IC, CE |
FAQs
Q: What is the Ubiquiti UVC-AI-Theta-Lens-360?
A: The UVC-AI-Theta-Lens-360 is an ultra-wide 360° 4 MP interchangeable lens for the AI Theta Hub, designed to deliver immersive panoramic coverage in large or busy indoor spaces.
Q: What camera sensor and resolution does the lens offer?
A: It features a 12 MP CMOS sensor and outputs a 4 MP image at 2560 x 2560 resolution, with a full 180° horizontal, vertical, and diagonal field of view.
Q: What are the physical design and mounting options?
A: The lens is housed in an aluminum alloy and polycarbonate enclosure, weighs just 15 g (0.5 oz), and includes a standard flush mount for seamless wall or ceiling installation.
Q: What are the power, environmental, and performance specs?
A: Powered via the AI Theta Hub’s proprietary 5 V DC (0.5 A) supply, it uses up to 2.5 W. It operates in temperatures from –20 °C to 40 °C with 10–90% non-condensing humidity. Its maximum frame rate is 20 fps.
Q: For what use cases is the UVC-AI-Theta-Lens-360 ideal?
A: It's perfect for panoramic monitoring in areas like retail floors, lobbies, and open-plan offices—its 360° coverage ensures comprehensive visibility in high-traffic or wide-angle environments.
